The Epitome of Lean


Fastener manufacturer and turned parts subcontractor Technifast has transformed its business over the past three years, doubling the turnover generated by production of parts at its Corby factory to £120,000 per month.

Not only is turnover up but profitability has also increased. It is largely down to lights-out running made possible by the latest, modern, 32 mm bar capacity Cincom lathes, two (soon to be three) of which are equipped with swarf conveyors and LFV (low frequency vibration) software. The latter allows reliable, uninterrupted, unattended running, as it is not necessary to stop the machines to clear away stringy swarf that can damage components and shorten tool life.

More efficient turning is only part of the story, however. Many other production aids have been introduced under Mr Speed’s ongoing initiative ‘to make one improvement to the operation every day’. The last three years has seen investment not only in six new Cincoms, the final one due to arrive in March 2023, but a host of other equipment as well.

Three decades of progression

The period from 2019 to the present has accelerated Technifast’s progression from purely a fastener manufacturing company, which was started by Mr Speed’s father John in 1990. Business prospered and Mr Speed senior started responding to an increasing number of requests for precision-turned components. A succession of second-hand Cincom lathes was purchased to fulfil the work. They were mainly of 20 mm capacity, plus a couple of 16 mm bar machines. Their continued arrival prompted a move in 2005 to much larger premises on the Oakley Hay Industrial Estate in Corby.

The first CNC lathe purchase, in 1992, was a Cincom L16. At the time, it was virtually impossible for Technifast not to buy this twin-spindle machine or a similar production lathe, as the company had just received an order for an unusually large quantity of 100,000 bespoke fasteners and the Emi-Mec Sprint plugboard lathes on the shop floor were unsuitable for the work.

Technifast continued to receive orders for parts in quantities from a few hundred up to 200,000, so over the ensuing 16 years, 15 further Cincoms were purchased, some of which are recent models that have replaced older versions.

Chipbreaking software enables unattended running

The first lathe to be purchased from new was a Cincom L20-VIIILFV with a Mitsubishi control that allowed low frequency vibration operation. It arrived in 2018 and was an eye-opener for Louis Speed in three respects.

The first surprise was the big improvement in dimensional accuracy, surface quality and repeatability that can be attained compared with using second-hand machines. Notable also was the speed of changeover and the third and most important aspect was the low frequency vibration functionality.

Mr Speed said, “LFV is able to fragment long strands of swarf into shorter chips, avoiding entanglement in the cutting zone and preventing clogging of the working area. It is especially effective when turning, grooving, parting and drilling certain materials like stainless steel and plastics, which tend to generate stringy swarf.

“Even mild steel previously caused problems. For example, drilling spacers could not be left to run overnight due to difficulty with swarf accumulation. Now we have no problems with lights-out running. When producing parts requiring a short cycle time, the bar magazine has run out by the time we arrive the next morning.”

Continued investment

Two further 20 mm capacity Cincoms, A20-VIIs, were installed in 2020. They were purchased for the production of price-sensitive components, the advantage being that the machines cost less than L20-series sliders as they have a lower specification, and LFV is not included.

The first was already on the shop floor when the initial Covid-19 lockdown was imposed, which was fortuitous as Technifast immediately received a large order for hand sanitiser components. The machine started running 24/7 to produce the components, half-paying for itself before the contract ended. Subsequently, towards the end of 2021, a third A20-VII was installed with a newly available Fanuc control capable of running LFV programs.

After LFV technology had been launched in 2017, and Mr Speed had subsequently gained an insight into the far-reaching benefits of the chipbreaking software through the use the following year of the L20-VIIILFV, he took the decision in mid-2021 to invest in an L32-VIIILFV to upgrade his 32 mm capacity. It was followed by a second in August 2020 and a third is on order, which is the machine mentioned earlier that is due for installation in March next year.

The first thing Mr Speed noticed about the new generation of L32s is, as with the 20 mm lathes, how much quicker they are to set than the model he bought second-hand in 2007, which was built in 1999. A further advantage is that the Iemca Boss bar magazine feeding the latest lathes can comfortably handle stock down to 6 mm diameter with the requisite guide channel, whereas with the earlier L32 it was not feasible to process bar of even double that diameter.

The second aspect of the new design that he exploited straight away was the ability to remove the guide bush for more economical production of parts with short length-to-diameter ratios up to approximately 2.5 to 1. It means that the expense of buying various bush inserts to accommodate different stock diameters is avoided, and less expensive bar can be purchased.

As this L32-VIIILFV had become a permanent GBL lathe, the second model installed adjacent to it has its guide bush kept in place all the time for sliding-head turning of shaft-type components.

Recycling for increased profit

Mr Speed concluded by offering a piece of advice: “One thing I would like to impress on all sliding-head turned parts machinists, almost all of whom use neat oil as a coolant and lubricant, is that they should spin their swarf to reclaim the residual oil it contains.

“We recycle and reuse 100 percent of the oil in the swarf from our nine Citizen lathes, so we only need to buy one or two 205-litre barrels of oil per year to top up the levels in our machines.

“If we did not spin our swarf, we would need to buy dozens of barrels every year at a cost of around £750 each, so the monetary saving is huge. In addition, we get a better price from recycling swarf that is dry – and we are also helping the environment.”
